M16 Circular power connectors KLS15-254-M16 All Products in Circular power connectors

M16 Circular power connectors


  Product Images
M16 Circular power connectors M16 Circular power connectors M16 Circular power connectors M16 Circular power connectors


  Product Information
M16 Circular Connector ( Water proof  Ip≥55 )
Subminiature Circular Connector are widely useed for the Hi-Tech trade. thread type. Used in the installation of the panel, small, exquisite and sensitive.

Order Information:
KLS15-254-M16-2M1
                    (1) (2)(3)
(1) M16:  M16 Shell Size
(2) 2:  2 pins     (2,3,4,5,6,7,8,9pins)
(3) F1- Plug Socket        F2-Docking Plug           F3-Plug Pin
     M1- Receptacle Pin   M2-Receptacle Socket  M3-Flange Receptacle Pin   M4-Flange Receptacle Socket


TYPE TYPE Pins Ordering Water-proof

　

 Plug Socket 2 M16-2F1 IP55
3 M16-3F1 IP55
4 M16-4F1 IP55
Plug Socket 5 M16-5F1 IP55
Plug Socket 6 M16-6F1 IP55
7 M16-7F1 IP55
8 M16-8F1 IP55
9 M16-9F1 IP55



 Docking Plug 2 M16-2F2 IP55
3 M16-3F2 IP55
4 M16-4F2 IP55
Docking Plug 5 M16-5F2 IP55
Docking Plug 6 M16-6F2 IP55
7 M16-7F2 IP55
8 M16-8F2 IP55
9 M16-9F2 IP55



 Plug Pin 2 M16-2F3 IP55
3 M16-3F3 IP55
4 M16-4F3 IP55
Plug Pin 5 M16-5F3 IP55
Plug Pin 6 M16-6F3 IP55
7 M16-7F3 IP55
8 M16-8F3 IP55
9 M16-9F3 IP55



 Receptacle Pin 2 M16-2M1 IP55
3 M16-3M1 IP55
4 M16-4M1 IP55
Receptacle Pin 5 M16-5M1 IP55
Receptacle Pin 6 M16-6M1 IP55
7 M16-7M1 IP55
8 M16-8M1 IP55
9 M16-9M1 IP55







 Receptacle Socket 2 M16-2M2 IP55
3 M16-3M2 IP55
4 M16-4M2 IP55
Receptacle Socket 5 M16-5M2 IP55
Receptacle Socket 6 M16-6M2 IP55
7 M16-7M2 IP55
8 M16-8M2 IP55
9 M16-9M2 IP55



 Flange Receptacle Pin 2 M16-2M3 IP55
3 M16-3M3 IP55
4 M16-4M3 IP55
Flange Receptacle Pin 5 M16-5M3 IP55
Flange Receptaclet Pin 6 M16-6M3 IP55
7 M16-7M3 IP55
8 M16-8M3 IP55
9 M16-9M3 IP55

Flange Receptaclet Socket 2 M16-2M4 IP55
3 M16-3M4 IP55
4 M16-4M4 IP55
Flange Receptaclet Socket 5 M16-5M4 IP55
Flange Receptaclet Socket 6 M16-6M4 IP55
7 M16-7M4 IP55
8

9		 M16-8M4

M16-9M4
 IP55

IP55

Part No.Description PCS/CTN G.W.(KG) CMB(m3) Order Qty. Time Order
KLS15-254-M16-2F1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 2Pin,Plug Socket.
KLS15-254-M16-2F2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 2Pin,Docking Plug Pin.
KLS15-254-M16-2F3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 2Pin,Plug Pin.
KLS15-254-M16-2M1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 2Pin,Receptacle Pin.
KLS15-254-M16-2M2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 2Pin,Receptacle Socket.
KLS15-254-M16-2M3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 2Pin,Flange Receptacle Pin.
KLS15-254-M16-2M4Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 2Pin,Flange Receptaclet Socket.
KLS15-254-M16-3F1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 3Pin,Plug Socket.
KLS15-254-M16-3F2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 3Pin,Docking Plug Pin.
KLS15-254-M16-3F3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 3Pin,Plug Pin.
KLS15-254-M16-3M1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 3Pin,Receptacle Pin.
KLS15-254-M16-3M2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 3Pin,Receptacle Socket.
KLS15-254-M16-3M3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 3Pin,Flange Receptacle Pin.
KLS15-254-M16-3M4Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 3Pin,Flange Receptaclet Socket.
KLS15-254-M16-4F1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 4Pin,Plug Socket.
KLS15-254-M16-4F2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 4Pin,Docking Plug Pin.
KLS15-254-M16-4F3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 4Pin,Plug Pin.
KLS15-254-M16-4M1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 4Pin,Receptacle Pin.
KLS15-254-M16-4M2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 4Pin,Receptacle Socket.
KLS15-254-M16-4M3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 4Pin,Flange Receptacle Pin.
KLS15-254-M16-4M4Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 4Pin,Flange Receptaclet Socket.
KLS15-254-M16-5F1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 5Pin,Plug Socket.
KLS15-254-M16-5F2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 5Pin,Docking Plug Pin.
KLS15-254-M16-5F3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 5Pin,Plug Pin.
KLS15-254-M16-5M1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 5Pin,Receptacle Pin.
KLS15-254-M16-5M2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 5Pin,Receptacle Socket.
KLS15-254-M16-5M3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 5Pin,Flange Receptacle Pin.
KLS15-254-M16-5M4Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 5Pin,Flange Receptaclet Socket.
KLS15-254-M16-6F1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 6Pin,Plug Socket.
KLS15-254-M16-6F2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 6Pin,Docking Plug Pin.
KLS15-254-M16-6F3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 6Pin,Plug Pin.
KLS15-254-M16-6M1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 6Pin,Receptacle Pin.
KLS15-254-M16-6M2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 6Pin,Receptacle Socket.
KLS15-254-M16-6M3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 6Pin,Flange Receptacle Pin.
KLS15-254-M16-6M4Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 6Pin,Flange Receptaclet Socket.
KLS15-254-M16-7F1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 7Pin,Plug Socket.
KLS15-254-M16-7F2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 7Pin,Docking Plug Pin.
KLS15-254-M16-7F3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 7Pin,Plug Pin.
KLS15-254-M16-7M1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 7Pin,Receptacle Pin.
KLS15-254-M16-7M2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 7Pin,Receptacle Socket.
KLS15-254-M16-7M3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 7Pin,Flange Receptacle Pin.
KLS15-254-M16-7M4Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 7Pin,Flange Receptaclet Socket.
KLS15-254-M16-8F1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 8Pin,Plug Socket.
KLS15-254-M16-8F2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 8Pin,Docking Plug Pin.
KLS15-254-M16-8F3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 8Pin,Plug Pin.
KLS15-254-M16-8M1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 8Pin,Receptacle Pin.
KLS15-254-M16-8M2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 8Pin,Receptacle Socket.
KLS15-254-M16-8M3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 8Pin,Flange Receptacle Pin.
KLS15-254-M16-8M4Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 8Pin,Flange Receptaclet Socket.
KLS15-254-M16-9F1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 9Pin,Plug Socket.
KLS15-254-M16-9F2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 9Pin,Docking Plug Pin.
KLS15-254-M16-9F3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 9Pin,Plug Pin.
KLS15-254-M16-9M1Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 9Pin,Receptacle Pin.
KLS15-254-M16-9M2Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 9Pin,Receptacle Socket.
KLS15-254-M16-9M3Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 9Pin,Flange Receptacle Pin.
KLS15-254-M16-9M4Circular Connector With Panel Mount Type,Water-proof IP55,Shell Size:M16, 9Pin,Flange Receptaclet Socket.
